Look at this rectangle on the board. It is 6 squares wide and 4 squares tall, with one straight line drawn from corner to corner.
That line splits the rectangle into two triangles. What fraction of the whole rectangle is each triangle?
Take three hands-up answers before confirming half. Do not say the area rule yet, let the word "half" hang so it pays off in Watch and Notice.
On the board, perpendicular height means how far the top point stands straight up above the base, measured at a right angle, never along the slanting side. We will look at four triangles, each with area ½ × base × height. For the first ones, watch how each sits as half of a box with the same base and height, then see what happens to the height on the last one.
Right-angled, base 6, height 4: box overlay shows the triangle is half of the 6×4 rectangle, whole box 24 cm², so ½ × 6 × 4 = 12 cm². Point at the two equal halves.
Scalene, base 8, height 5: ask the class to predict first, then ½ × 8 × 5 = 20 cm².
Isosceles, base 10, height 6: ½ × 10 × 6 = 30 cm².
Obtuse, base 9, height 4: perpendicular height drops outside the base. Hold out for this — the rule never flinches, ½ × 9 × 4 = 18 cm². Point to the slanting side and ask "is this the height?" — no, and that is the whole lesson.
Today we work through three triangles together on the board. First a right triangle with base 5 and height 4. Then a taller one with base 5 and height 8. Last a wide flat one with base 12 and height 3.
Before each answer appears, say what half of base times height comes to. For each one we also draw the rectangle it fits inside, so we can see the triangle is exactly half.
This is the guided practice round, we talk it through together, pupils take turns at the board and the class agrees or corrects out loud.
Drag the triangle legs in explore mode; the area readout confirms each prediction. The drag only needs to be close, the ½ × b × h calculation is the source of truth and the live readout confirms it. Sketch the enclosing rectangle by hand each time (the explore interactive shows one triangle at a time) so the half-rectangle picture is always on view.
Ask "why did doubling the height double the area, but the wide flat one is smaller?", hold out for pupils naming that both base and height decide the area.
In your maths copy, sketch the three triangles from Try It Together: base 5 height 4, base 5 height 8, and base 12 height 3. Label the base and the perpendicular height on each one.
Under each triangle, write ½ × b × h = area and put in the units (cm²). On at least one, draw a dashed rectangle around it so the half-rectangle picture lives on your page.
Walk the room, glancing for the perpendicular height being marked straight up from the base (not along the slant), this is whole-class copybook practice, not marking. Watch that pupils write cm² and not just cm.
Today we work out four triangle areas, then a trickier one where we know the area and find the missing height.
The stretch: a triangle has area 18 cm² and base 9 cm, how tall is it?
This is the practice round, pupils take turns at the board, check each answer, and the class confirms before moving on.
Keep the board work brisk rather than over-explaining.
The four straight ones build from small to a square-ish case to the flat one, pupils get faster each time. Then the find-the-height stretch reverses the rule: area 18 = ½ × 9 × h, so 18 = 4.5 × h, so h = 4 cm. Work this one on the board without the interactive, the shape-measurer only reads area off a dragged shape, so it cannot check a missing height. Work back from the area rather than forward, this is where the strongest pupils stretch and the rest see the rule run in reverse.
